8” Radial flow Borewell Submersible Pumps - TRE

8” Radial flow Borewell Submersible Pumps Radial flow Borewell Submersible

Product Features
Available in radial flow impeller designs
Dynamically balanced LTB impellers
Special LTB and nitrile rubber bearing bushes for high wear resistance and longer life
Diffusers of gunmetal and housings are of high grade cast iron to ensure long life
Built in NRV with minimum friction
Easily rewindable Squirrel cage motor of water-cooled, designed for 350 - 440 V, 50 Hz, AC power supply
Stainless steel stator shell to prevent rust formation
Specially designed carbon thrust bearing
High quality seal rings and sand guards to protect motor from sand entry
High quality water-resistant polymer insulated wires for longer life even under adverse voltage conditions
Pressure diaphragm to compensate excess pressure due to heating up of filled water

Material Of Construction
Part Name Material Part Name Material
Impeller LTB - 2 Motor body AISI 304
Diffuser Gunmetal Bearing housing CI FG 200
Pump shaft AISI 410 Motor shaft 55C8
Sleeve AISI 410 Journal bush LTB-4
Bearing bush NBR Thrust bearing AISI 420 - Carbon
Non return valve Gunmetal Winding wire PVC insulated copper

Applications
» Domestic and community water supply.
» Water supply to high rise buildings, housing complexes, bungalows and Industries
» Irrigation of farms
» Cattle and poultry farms
» Dairies
» Cooling water circulating systems
» Fire fighting systems
» Fountains.
