5” / 7” Mixed flow Borewell Submersible Pumps - TMIF / TMVS

Product Features

	Available in mixed flow impeller designs
	High quality dynamically balanced LTB impellers
	Special LTB and nitrile rubber bearing bushes for high wear resistance and longer life
	Bowls are of high grade cast iron to ensure long life
	Built in NRV with minimum friction
	Easily rewindable Squirrel cage motor of water-cooled, designed for 350 - 440 V, 50 Hz, AC power supply
	Stainless steel stator shell to prevent rust formation
	Specially designed carbon thrust bearing
	High quality seal rings and sand guards to protect motor from sand entry
	High quality water-resistant polymer insulated wires for longer life even under adverse voltage conditions
	Pressure diaphragm to compensate excess pressure due to heating up of filled water

Material Of Construction

Part Name	Material	Part Name	Material
Impeller	LTB-2	Motor body	AISI 304
Bowl	CI FG 200	Bearing housing	CI FG 200
Pump shaft	AISI 410	Motor shaft	AISI 431 (TMIF) / 55C8 (TMVS)
Sleeve	AISI 410	Journal bush	Carbon (TMIF) / LTB-4 (TMVS)
Bearing bush	NBR	Thrust bearing	AISI 420-Carbon
Non return valve	Gunmetal	Winding wire	Polywrapped copper

Applications

» Domestic and community water supply.
» Water supply to high rise buildings, housing complexes, bungalows and Industries
» Irrigation of farms
» Cattle and poultry farms
» Dairies
» Cooling water circulating systems
» Fire fighting systems
» Fountains.
